集指(zhi)导思想创造、盛产、发卖业务办(ban)理
于立体式的从一而终于石雕勘探和代加工设备技能的我国级高新区手工艺工厂
| 称号 | Name | 单元/Unit | 2QYK-3600 |
2QYK-3300 |
2QYK-3600 |
2QYK-4000/4200 | 2QYK-5000 |
| 范例 | Type | A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
|
| 锯片直径 | Blade diameter |
mm |
Φ3000 | Φ3300 | Φ3600 |
Φ4000/Φ4200 |
Φ5000 |
| 最大切割深度 | Max.cutting depth |
mm |
1250 | 1400 | 1500 | 1750/1850 | 2250 |
|
主机结构额定功率 |
Power ofmain motor |
kw | 55x2 | 55x2 | 55x2 | 65X2 | 65X2 |
|
高压油泵机电工程工作效率 |
Power of pump motor |
kw |
3.5 | 3.5 | 3.5 | 4 | 4 |
| 路程机电功率 |
Power of stroke motor |
kw |
2.2 | 2.2 | 2.2 | 3 | 4 |
| 纵向换轨机电功率 |
|
kw |
0.75x2 | 0.75x2 | 0.75x2 | 1.1X2 | 1.1X2 |
|
铸件工作效率 |
Gross power |
kw |
117.2 | 117.2 | 117.2 | 139.2 | 140.2 |
|
的形状尽寸 |
Dimensions(LxWxH) |
mm | 3200x2100x2800 | 3500x2200x3200 | 3800x2200x3100 | 420X2100X3500 | 5200X2200X4200 |
|
部件食用量 |
Gross weight |
kg | 7000-8500 | 7000-8500 | 7500-10000 | 9500-11500 | 9500-12500 |
| 切割宽度 | Cutting width of TypeA |
mm |
1360-1900 | 1360-1900 | 1360-1900 | 1950-2450 | 2000-2500 |
|
|
TypeB |
mm |
1800-2300 | 1800-2300 | 1900-2400 | 2400-2900 | 2400-2900 |
|
|
TypeC |
mm |
2200-2700 | 2200-2700 |
2300-2800 |
2800-3300 | 2800-3300 |
|
|
TypeD |
mm |
2700-3200 |
2700-3200 |
2700-3200 | 3200-3700 | 3200-3700 |
| 一米四机台 |
|
|
|
|
|
|
|
|
加工零件量用 |
Gross weight |
kg |
7000 | 7500 | 7800 | / | / |
| 款式尺寸大小 | Dimensions(LxWxH) |
mm |
3200z1500z2630 |
3500x1500x2880 |
3700x1500x3050 |
/ | / |
|
裁割尺寸 |
Cutting width |
mm |
1380-1880 | 1380-1880 | 1380-1880 | / | / |
| 四驱机型 |
|
|
|
|
|
|
|
| 纵横驱动机电功率 |
|
kw | 1.5x2 | 1.5x2 | 1.5x2 | 1.5X2 | 1.5X2 |
| 总功率 |
Gross power |
kw | 116.5 | 116.5 | 116.5 | 137 | 137 |
